MIG Welder Ultimate Guide

Types Of Metal Inert Gas Welder (MIG Welder), Gas Metal Arc Welding Machine (MAG Welder Or GMAW) & What The Difference Is Between Our Various Models - MIG Welder Ultimate Guide

If you are interested in our MIG Welder (MIG welding machine), you may be wondering what the difference is between our various models of MIG Welder, and which type of welding may be more useful or more versatile.

NO. Model Input Output Process Features Key Component Wirespool Capable Recommend Wire(mm) Thickness of welding material（mm）
Phase                (PH) Voltage                  (V) Hertz            (Hz) Polarity Current Range (A) MIG             MAG Flux-Cored Pulse Double Pulse Spot Welding MMA Lift-TIG 2T/4T Synergic Inductance Spool Gun Direct torch
connector		 Dual Voltage      Save /Load IGBT IGBT Module Mosfet S SS  AlSi/ AlMg
1 FC-120 1 220 50/60 DC 30~120 ● ● ● ● ● 1kg 0.8~1.0 0.6~4.0 0.6~4.0 /
2 FC-120ECO 1 220 50/60 DC 30~120 ● ● ● ● ● 1kg 0.8~1.0 0.6~4.0 0.6~4.0 /
3 FC-120F 1 220 50/60 DC 30~120 ● ● ● 1kg 0.8~1.0 0.6~4.0 0.6~4.0 /
4 FC-120X 1 220 50/60 DC 30~120 ● ● ● ● 1kg 0.8~1.0 0.6~4.0 0.6~4.0 /
5 FC-120S 1 220 50/60 DC 10~120 ● ● ● ● ● ● 1kg 0.8~1.0 0.6~4.0 0.6~4.0 /
6 MIG-140 1 220 50/60 DC 30~140 ● ● ● ● ● ● 1kg/5kg 0.8~1.0 1.0~5.0 1.0~5.0 /
7 MIG-160 1 220 50/60 DC 30~160 ● ● ● ● ● ● 1kg/5kg 0.8~1.0 1.0~6.0 1.0~6.0 /
8 MIG-140C 1 220 50/60 DC 30~140 ● ● ● ● ● ● ● 1kg/5kg 0.8~1.0 1.0~5.0 1.0~5.0 /
9 MIG-160C 1 220 50/60 DC 30~160 ● ● ● ● ● ● ● 1kg/5kg 0.8~1.0 1.0~6.0 1.0~6.0 /
10 MIG-160P 1 220 50/60 DC 30~160 ● ● ● ● ● ● ● ◑ ● 1kg/5kg 0.6~1.0 1.0~6.0 1.0~6.0 1.0~6.0
11 MIG-180P 1 220 50/60 DC 30~180 ● ● ● ● ● ● ● ◑ ● 1kg/5kg 0.6~1.0 1.0~7.0 1.0~7.0 1.0~7.0
12 MIG-200DP 1 220 50/60 DC 30~200 ● ● ● ● ● ● ● ● ● ● ● ● 1kg/5kg 0.6~1.2 1.0~8.0 1.0~8.0 1.0~8.0
13 MIG-180 1 220 50/60 DC 30~180 ● ● ● ● ● ● ● ◑ ● 1kg/5kg 0.6~1.0 1.0~7.0 1.0~7.0 /
14 MIG-200 1 220 50/60 DC 30~200 ● ● ● ● ● ● ● ◑ ● 1kg/5kg 0.6~1.0 1.0~8.0 1.0~8.0 /
15 MIG-160X 1 220 50/60 DC 30~160 ● ● ● ● ● ● ● 1kg/5kg 0.8~1.0 1.0~6.0 1.0~6.0 1.0~6.0
16 MIG-180X 1 220 50/60 DC 30~180 ● ● ● ● ● ● ● 1kg/5kg 0.8~1.0 1.0~7.0 1.0~7.0 1.0~7.0
17 MIG-200X 1 220 50/60 DC 30~200 ● ● ● ● ● ● ● 1kg/5kg 0.8~1.2 1.0~8.0 1.0~8.0 1.0~8.0
18 MIG-140I 1 220 50/60 DC 30~140 ● ● ● ● ● ● ● ◑ ● 1kg/5kg 0.8~1.0 1.0~5.0 1.0~5.0 /
19 MIG-160I 1 220 50/60 DC 30~160 ● ● ● ● ● ● ● ◑ ● 1kg/5kg 0.8~1.0 1.0~6.0 1.0~6.0 /
20 MIG-180I 1 220 50/60 DC 30~180 ● ● ● ● ● ● ● ◑ ● 1kg/5kg 0.8~1.0 1.0~7.0 1.0~7.0 /
21 MIG-200I 1 220 50/60 DC 30~200 ● ● ● ● ● ● ● ◑ ● 1kg/5kg 0.8~1.0 1.0~8.0 1.0~8.0 /
22 MIG-200DPL 1 220 50/60 DC 60~200 ● ● ● ● ● ● ● ● ● ● ● 1kg/5kg 0.8~1.2 1.0~8.0 1.0~8.0 1.0~8.0
23 MIG-200DPLUS  1 220 50/60 DC 60~200 ● ● ● ● ● ● ● ● ● ● ● 15kg 0.8~1.2 1.0~8.0 1.0~8.0 1.0~8.0
24 MIG-250L 1 220 50/60 DC 50~250 ● ● ● ● 15kg 0.8~1.2 1.0~10.0 1.0~10.0 /
25 MIG-270L 3 380 50/60 DC 50~270 ● ● ● ◑ ● 15kg 0.8~1.2 1.0~12.0 1.0~12.0 /
26 MIG-250T 1 220 50/60 DC 50~250 ● ● ● ● ● ● 20kg 0.8~1.2 1.0~10.0 1.0~10.0 /
27 MIG-270T 3 380 50/60 DC 50~270 ● ● ● ● ● ◑ ● 20kg 0.8~1.2 1.0~12.0 1.0~12.0 /
28 MIG-200T 1 220 50/60 DC 50~200 ● ● ● ● ● ● ● ● 20kg 0.8~1.2 1.0~8.0 1.0~8.0 1.0~8.0
29 MIG-250T 1 220 50/60 DC 50~250 ● ● ● ● ● ● ● ● 20kg 0.8~1.2 1.0~10.0 1.0~10.0 1.0~10.0
30 MIG-250T3 3 380 50/60 DC 50~250 ● ● ● ● ● ● ● ● 20kg 0.8~1.2 1.0~10.0 1.0~10.0 1.0~10.0
31 MIG-300T 3 380 50/60 DC 50~300 ● ● ● ● ● ● ● ● 20kg 0.8~1.2 2.0~16.0 2.0~16.0 2.0~16.0
32 MIG-400T 3 380 50/60 DC 50~400 ● ● ● ● ● ● ● 20kg 0.8~1.6 2.0~30.0 2.0~30.0 2.0~20.0
33 MIG-500T 3 380 50/60 DC 50~500 ● ● ● ● ● ● ● 20kg 0.8~1.6 2.0~50.0 2.0~50.0 2.0~20.0
34 MIG-350 3 380 50/60 DC 50~330 ● ● ● ● ● ● ● 20kg 0.8~1.6 2.0~30.0 2.0~30.0 /
35 MIG-400 3 380 50/60 DC 50~400 ● ● ● ● ● ● ● 20kg 0.8~1.6 2.0~40.0 2.0~40.0 /
36 MIG-500 3 380 50/60 DC 50~500 ● ● ● ● ● ● ● 20kg 0.8~1.6 2.0~50.0 2.0~50.0 /
37 MIG-270D 3 380 50/60 DC 60~270 ● ● ● ● ● ● 20kg 0.8~1.2 1.0~12.0 1.0~12.0 /
38 MIG-350D 3 380 50/60 DC 60~350 ● ● ● ● ● ● 20kg 0.8~1.6 2.0~30.0 2.0~30.0 /
39 MIG-500D 3 380 50/60 DC 60~500 ● ● ● ● ● ● 20kg 0.8~1.6 2.0~50.0 2.0~50.0 /
40 MIG-315L PRO 1/2/3 150~550 50/60 DC 50~310 ● ● ● ● ● ● ● ● ● 15kg 0.8~1.2 2.0~16.0 2.0~16.0 /
41 MIG-250PRO 3 220/440 50/60 DC 40~200（220V）                                  40~250（440V）                            ● ● ● ● ● ● ● 15kg 0.8~1.2 1.0~10.0 1.0~10.0 /
42 MIG-320PRO 3 220/440 50/60 DC 40~200（220V）                                  40~320（440V）                            ● ● ● ● ● ● ● 15kg 0.8~1.2 2.0~16.0 2.0~16.0 /
43 MIG-250P.PRO 3 220/440 50/60 DC 40~200（220V）                                  40~250（440V）                            ● ● ● ● ● ● ● ● ● ● 15kg 0.8~1.2 1.0~10.0 1.0~10.0 1.0~10.0
44 MIG-320P.PRO 3 220/440 50/60 DC 40~200（220V）                                  40~320（440V）                            ● ● ● ● ● ● ● ● ● ● 15kg 0.8~1.2 2.0~16.0 2.0~16.0 1.0~16.0
45 MIG-350P.PRO 3 220/440 50/60 DC 40~250（220V）                                                          40~300（440V） ● ● ● ● ● ● ● ● ● ● 20kg 0.8~1.6 2.0~30.0 2.0~30.0 1.0~20.0
46 MIG-500P.PRO 3 220/440 50/60 DC 30~300（220V）                  40~500（440V）                            ● ● ● ● ● ● ● ● ● ● 20kg 0.8~1.6 2.0~50.0 2.0~50.0 1.0~20.0
47 MIG-230  1 220 50/60 DC 10~230 ● ● ● ● ● ● ● ● ● ◑ ◑ ● 15kg 0.8~1.2 0.8~10.0 0.8~10.0 0.4~10.0
48 MIG-230MINI 1 220 50/60 DC 10~230 ● ● ● ● ● ● ● ● ● ● 5kg 0.8~1.2 0.8~10.0 0.8~10.0 0.4~10.0
49 MIG-280  3 380 50/60 DC 25~250 ● ● ● ● ● ● ● ● ● ◑ ◑ ● ● 20kg 0.8~1.2 0.8~12.0 0.8~12.0 0.4~12.0
50 MIG-280PLUS  3 380 50/60 DC 25~250 ● ● ● ● ● ● ● ● ● ◑ ◑ ● ● 20kg 0.8~1.2 0.8~12.0 0.8~12.0 0.4~12.0
51 MIG-350 3 380 50/60 DC 60~350 ● ● ● ● ● ● ● ● ● ● 20kg 0.8~1.6 0.8~30.0 0.8~30.0 0.4~20.0
52 MIG-350W 3 380 50/60 DC 60~500 ● ● ● ● ● ● ● ● ● ● 20kg 0.8~1.6 0.8~30.0 0.8~30.0 0.4~20.0
53 MIG-500 3 380 50/60 DC 60~350 ● ● ● ● ● ● ● ● ● ● 20kg 0.8~1.6 0.8~50.0 0.8~50.0 0.4~20.0
54 MIG-500W 3 380 50/60 DC 60~500 ● ● ● ● ● ● ● ● ● ● 20kg 0.8~1.6 0.8~50.0 0.8~50.0 0.4~20.0
KEY: ● Own/Adjustable/Access       ◑  Optional/Built-in
