If you are interested in our manual metal arc welding machine, you may be wondering what the difference is between our various models of mma welder, and which type of welding may be more useful or more versatile.
| NO. | Model | Input | Output | Process | Features | Key Component | Recommend Electrode(mm) | Thickness of welding material（mm） | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Phase (PH) | Voltage (V) | Hertz (Hz) | Polarity | Current Range (A) | MMA | Lift-TIG | Arc Gouge | Remote Control | VRD | Hot Start | Arc Force | OCV(80V) | Synergic | Dual Voltage | IGBT | IGBT Module | Mosfet | S | SS | Ni | CI | |||
| 1 | ARC-120mini | 1 | 220 | 50/60 | DC | 20~120 | ● | ● | 1.6~3.2 | 1.5~4.0 | 1.5~4.0 | 1.5~4.0 | 1.5~4.0 | |||||||||||
| 2 | ARC-160X | 1 | 220 | 50/60 | DC | 20~160 | ● | ◑ | ◑ | ◑ | ◑ | ◑ | ● | 1.6~4.0 | 1.5~6.0 | 1.5~6.0 | 1.5~6.0 | 1.5~6.0 | ||||||
| 3 | ARC-200X | 1 | 220 | 50/60 | DC | 20~200 | ● | ◑ | ◑ | ◑ | ◑ | ◑ | ● | 1.6~5.0 | 1.5~12.0 | 1.5~12.0 | 1.5~12.0 | 1.5~12.0 | ||||||
| 4 | ARC-160 | 1 | 220 | 50/60 | DC | 20~160 | ● | ● | ● | ◑ | ◑ | ◑ | ● | 1.6~4.0 | 1.5~6.0 | 1.5~6.0 | 1.5~6.0 | 1.5~6.0 | ||||||
| 5 | ARC-200 | 1 | 220 | 50/60 | DC | 20~200 | ● | ● | ● | ◑ | ◑ | ◑ | ● | 1.6~5.0 | 1.5~12.0 | 1.5~12.0 | 1.5~12.0 | 1.5~12.0 | ||||||
| 6 | ARC-250 | 1 | 220 | 50/60 | DC | 30~250 | ● | ◑ | ◑ | ◑ | ● | ● | 1.6~5.0 | 1.5~12.0 | 1.5~12.0 | 1.5~12.0 | 1.5~12.0 | |||||||
| 7 | ARC-160D | 1 | 220 | 50/60 | DC | 20~160 | ● | ● | ● | ● | ● | ● | ◑ | ● | 1.6~4.0 | 1.5~6.0 | 1.5~6.0 | 1.5~6.0 | 1.5~6.0 | |||||
| 8 | ARC-200D | 1 | 220 | 50/60 | DC | 20~200 | ● | ● | ● | ● | ● | ● | ◑ | ● | 1.6~5.0 | 1.5~12.0 | 1.5~12.0 | 1.5~12.0 | 1.5~12.0 | |||||
| 9 | ARC-320D | 3 | 380 | 50/60 | DC | 30~320 | ● | ● | ● | ● | ● | ● | ● | 2.5~6.0 | >13 | >13 | >13 | >13 | ||||||
| 10 | ARC-315 | 3 | 380 | 50/60 | DC | 20~280 | ● | ● | ● | ● | ● | ● | 1.6~5.0 | 1.5~12.0 | 1.5~12.0 | 1.5~12.0 | 1.5~12.0 | |||||||
| 11 | ARC-400 | 3 | 380 | 50/60 | DC | 25~380 | ● | ● | ● | ● | ● | ● | ● | 2.5~6.0 | >13 | >13 | >13 | >13 | ||||||
| 12 | ARC-450 | 3 | 380 | 50/60 | DC | 25~420 | ● | ● | ● | ● | ● | ● | ● | ● | 2.5~6.0 | >13 | >13 | >13 | >13 | |||||
| 13 | ARC-500 | 3 | 380 | 50/60 | DC | 30~500 | ● | ● | ● | ● | ● | ● | ● | ● | 2.5~6.0 | >13 | >13 | >13 | >13 | |||||
| 14 | ARC-630 | 3 | 380 | 50/60 | DC | 30~630 | ● | ● | ● | ● | ● | ● | ● | ● | 2.5~6.0 | >13 | >13 | >13 | >13 | |||||
| 15 | MMA-140 | 1 | 220 | 50/60 | DC | 20~140 | ● | ◑ | ● | ◑ | ● | 1.6~3.2 | 1.5~4.0 | 1.5~4.0 | 1.5~4.0 | 1.5~4.0 | ||||||||
| 16 | MMA-160 | 1 | 220 | 50/60 | DC | 20~160 | ● | ◑ | ● | ◑ | ● | 1.6~4.0 | 1.5~6.0 | 1.5~6.0 | 1.5~6.0 | 1.5~6.0 | ||||||||
| 17 | MMA-180 | 1 | 220 | 50/60 | DC | 20~180 | ● | ◑ | ● | ◑ | ● | 1.6~5.0 | 1.5~12.0 | 1.5~12.0 | 1.5~12.0 | 1.5~12.0 | ||||||||
| 18 | MMA-200M | 1 | 220 | 50/60 | DC | 20~180 | ● | ◑ | ● | ● | 1.6~5.0 | 1.5~12.0 | 1.5~12.0 | 1.5~12.0 | 1.5~12.0 | |||||||||
| 19 | MMA-160CS | 1 | 110/220 | 50/60 | DC | 20-160（220V） 20-95 （110V） | ● | ◑ | ◑ | ● | ● | ● | 1.6~4.0 | 1.5~6.0 | 1.5~6.0 | 1.5~6.0 | 1.5~6.0 | |||||||
| 20 | MMA-200CS | 1 | 110/220 | 50/60 | DC | 20-200（220V） 20-120（110V） | ● | ◑ | ◑ | ● | ● | ● | 1.6~5.0 | 1.5~12.0 | 1.5~12.0 | 1.5~12.0 | 1.5~12.0 | |||||||
| 21 | MMA-300 | 3 | 380 | 50/60 | DC | 30~300 | ● | ◑ | ● | ● | 1.6~5.0 | 1.5~12.0 | 1.5~12.0 | 1.5~12.0 | 1.5~12.0 | |||||||||
| 22 | MMA-350 | 3 | 380 | 50/60 | DC | 40~350 | ● | ◑ | ● | ● | 2.5~6.0 | >13 | >13 | >13 | >13 | |||||||||
| 23 | MMA-400 | 3 | 380 | 50/60 | DC | 40~400 | ● | ● | ◑ | ● | ● | 2.5~6.0 | >13 | >13 | >13 | >13 | ||||||||
| 24 | MMA-550 | 3 | 380 | 50/60 | DC | 40~550 | ● | ● | ◑ | ● | ● | 2.5~6.0 | >13 | >13 | >13 | >13 | ||||||||
| KEY: ● Own/Adjustable/Access ◑ Optional/Built-in | ||||||||||||||||||||||||
