1. Compact design, lightweight, but robust.
2. User-friendly and cost-effective.
3. Build-in Arc Force, Anti-Stick, and Hot Start technology
4. enable easy arc starting, arc stability, and smoothness.
5. High-cost performance
| Model | ARC-160X |
|---|---|
| Power input AC(V) | 1pH 220V ±15% |
| Power input frequency(Hz) | 50/60 |
| Max. Load Power Capacity(kVA) | 7.1 |
| Rated current input(A) | 30 |
| Rated output current(A)/voltage(V) | 160/26.4 |
| Welding current range(A) | 20-160 |
| Open circuit voltage DC(V) | 62 |
| Rated duty cycle(%) | 50 |
| IP grade | IP21S |
| Insulation grade | F |
| Dimensions(mm) | 410*150*260 |
| N.W(kg) | 5.9 |
