CUT-160PRO IGBT Inverter Plasma Cutting Machine

In Stock
Welder Custom LabelCapable of welding and cutting through thick metal sheets
Welder Custom LabelClean cuts through rusty/painted metal
Welder Custom LabelHigh-performing and durable plasma torch

1. 3ph/220V input power allows even 160A cutting capacity.
2. Able to be connected with CNC equipment to achieve automatic cutting function; the connector is optional.
3. MULTI-FUNCTION two in one, optional MMA function.
4. Powerful cutting capacity, narrow cutting seam, and clean cutting edge.
5. 2T/4T self-locking function.
6. Pilot Arc Starting increases cutting capability and cutting speed, improving the service life of torch kit.
7. Heavy-duty cycle for industrial use.

Model

CUT-160PRO

Power input AC(V)

3ph 220V ±15%

Power input frequency(Hz)

50/60

Max. Load Power Capacity

29.3 kVA

Rated current input(A)

76.78

Rated output current(A)/voltage(V)

160/144

Max. cutting current (A)

160

Open circuit voltage DC(V)

320

Rated duty cycle(%)

60

Max.cutting thickness(mm)

55

IP grade

IP21

Insulation grade

F

Dimensions(mm)

615*380*635

Weight (KG)

35

Brochure

CUT-160PRO IGBT Inverter Plasma Cutting Machine CUT-160PRO IGBT Inverter Plasma Cutting Machine

Video
