1. IGBT inverter for high efficiency, simple operation, smooth precise cutting.
2. Pressure regulating valve does waterproof automatically, the gas meter was molded together with the machine, no need to install it. 3. Pilot arc starting increases cutting capability and cutting speed, improving the service life of the torch kit.
4. Adjustable post-flow function.
5. 2T/4T self-locking function.
6. Capable of cutting all metal plates.
7. O.H&O.C protection, for long-term use.
| Model | CUT-60 |
|---|---|
| Power input AC(V) | 1ph 220V ±15% |
| Power input frequency(Hz) | 50/60 |
| Max. Load Power Capacity | 10.7 |
| Rated current input(A) | 41 |
| Rated output current(A)/voltage(V) | 55/102 |
| Max. cutting current (A) | 55 |
| Open circuit voltage DC(V) | 360 |
| Rated duty cycle(%) | 60 |
| Max.cutting thickness(mm) | 25 |
| IP grade | IP21S |
| Insulation grade | F |
| Dimensions(mm) | 500*215*380 mm |
| Weight (KG) | 15 |
