1.Full bridge IGBT converter guarantees the stable output power
2.Multifunction welder for industrial use: MIG/MAG, Gasless flux-cored wire welding, and MMA.
3.The full digital control system, welding parameters can be adjusted independently; Stable arc output, and superior welding quality.
4.High efficiency and duty cycle, and no noise from arc welding rectifier.
5.Less spatter and high metal deposition rate; nice welding bead and less deformation.
6.MMA function is designed to weld various electrodes like acid.alkaline,stainless steel, cast iron, etc with excellent performance.
7.Ideal for use in outdoor and indoor conditions.
8.Operation safety protection against over-voltage, and low-voltage,over-current and over-heated.
| Model | MIG-315L PRO |
|---|---|
| Power input AC(V) | 1PH/2PH/3PH 150V-500V |
| Power input frequency(Hz) | 50/60 |
| Max. Load Power Capacity(kVA) | 15.7 |
| Rated current input(A) | 29 |
| Rated output current(A)/voltage(V) | 310/29.5(MIG), 270/30.8(MMA) |
| Welding current range(A) | 30-310(MIG), 30-270(MMA) |
| Open circuit voltage DC(V) | 62 |
| Rated duty cycle | 80% |
| Wire Feeding Speed(M/min) | 2～18 |
| IP grade | IP21S |
| Insulation grade | F |
| Dimensions(mm) | 647*367*542 |
| Weight (KG) | 22/28.5 |
| Wire Melting Type | spray transfer |
